Black mesh backrest 100,000 cycles
Automatic tension adjustment
Seat translation
Adjustable lumbar support
Height-adjustable and tiltable headrest
Lift. Nylon foot
In stock in black
Other colors on request
Laterally adjustable tension, non-return
Drawer seat with translation
Adjustable lumbar support
Height-adjustable and tiltable headrest
Lift. Nylon foot
In stock in black
Other colors on request
STRUCTURE
SEAT
Anatomically-shaped, glass-fiber-reinforced nylon support, 5 mm thick, with internal metal bars.
Injected polypropylene counter-shell (30/10 thick) secured to support with screws and inserts.
BACK
Glass-fiber-reinforced nylon support.
FILLING
SEAT
CFC-free polyurethane foam, density 40 kg/m3, thickness 65 mm. Water-based, non-polluting glue.
COVERING
SEAT
Fabric sewn and stapled to foam.
BACK
100% polyester mesh, high resistance.
LINK
Seat/back, with 7 mm thick, ribbed, glass-fiber reinforced nylon structure.
MECHANISM
Synchronized, 5-position locking system with backrest anti-retraction system and automatic intensity adjustment according to user’s weight. Seat depth adjustment, 50 mm travel. Seat height adjustment by double-cone gas spring, class 3, nominal stroke 130 mm, meeting DIN 4550/4551 standards. Lift KGS, class 3.
Manual lumbar support adjustment, 100 mm stroke.
FEET
5-spoke nylon pyramid base, glass-fibre reinforced – 68 mm.
Self-braking double-roller polyamide castors, diameter 50 mm, steel swivel diameter 11 mm.
ENVIRONMENT
The seat is made from 50% recycled raw materials, and is 90% recyclable.
STRUCTURE
SEAT
Anatomically-shaped, glass-fiber-reinforced nylon support, 5mm thick, with internal metal bars.
Injected polypropylene counter-shell (30/10 thick) secured to support with screws and inserts.
BACK
Glass-fiber-reinforced nylon support.
FILLING
SEAT
CFC-free polyurethane foam, density 40 kg/m3, thickness 65 mm. Water-based, non-polluting glue.
COVERING
SEAT
Fabric sewn and stapled to foam.
BACK
100% polyester mesh, high resistance.
LINK
Seat/back, with 7 mm ribbed, glass-fiber-filled nylon structure.
MECHANISM
Synchronized, 5-position locking system with backrest anti-retraction system, adjustable in intensity according to user’s weight by side crank. Seat depth adjustment, 50 mm travel. Seat height adjustment by double-cone gas spring, class 3, nominal stroke 130mm, compliant with DIN 4550/4551.
Manual lumbar support adjustment, stroke 100mm.
FEET
5-spoke nylon pyramid base, glass-fibre reinforced – 68 mm.
Self-locking double-roller polyamide castors, diameter 50 mm, steel swivel diameter 11 mm.
