Seat translation
Adjustable tension, anti-reverse
Height-adjustable backrest with “up and down” rack-and-pinion mechanism
Lift. Nylon foot
STRUCTURE
SEAT
Injected polypropylene support
Self-supporting injected polyamide counter-shell (30/10ᵉ thick) secured by screw and insert to support.
BACK
Injected polypropylene support
Injected polypropylene counter-shell (30/10ᵉ thick) clipped to support.
COVERING
SEAT
Non-deforming dynamic injected foam, bonded to the structure, density 30 kg/m3, thickness 50 mm
BACK
Non-deforming dynamic injected foam, bonded to the structure, density 30 kg/m3, thickness 40 mm
COVERING
Fabric glued to foam and stapled to polypropylene backing.
LINK
Seat/backrest, with black epoxy-painted hardened steel blade.
Protection with molded polypropylene housing.
MECHANISM
Synchronous system, lockable in 5 positions, manual adjustment lever.
Handle adjustment for backrest locking/unlocking and seat height adjustment by self-supporting gas spring, nominal stroke 140 mm.
Lift SHS Class 3.
Backrest height adjustment by ratchet on semi-rigid steel blade, “step by step” rack and pinion system.
FEATURES
5-spoke polyamide star (self-graining, glass-fiber-filled nylon) – 690 mm.
50 mm self-braking polyamide double-roller castors, 11 mm diameter steel pivot.
