Denzel

STRUCTURE
SEAT
Polypropylene ribbed support with internal metal reinforcement bars.
Polypropylene counter-shell (thickness 30/10) secured with screws and clipped to the support.
BACK
Glass-fibre reinforced polypropylene support.
Polypropylene lumbar support, height adjustable.

COVERING
SEAT
CFC-free polyurethane foam, bonded to the structure, density 40 kg/m3, thickness 45 mm.

COVERING
SEAT
Fabric glued to foam and stapled to polypropylene backing.
BACK
High-resistance 100% polyester mesh.

LINK
Seat/back, by reinforced polypropylene slat with metal inserts.

MECHANISM
Synchronous, single-lever system, lockable in 4 positions.
Seat height adjustment by self-supporting gas spring, class 3, SHS brand, nominal stroke 130 mm, complies with DIN 4550/4551.
Seat depth adjustment by lever, stroke 50 mm.

FEATURES
5-spoke polyamide star (self-graining, glass-fiber-filled nylon) – 680 mm.
Self-braking double-roller polyamide castors, diameter 50 mm, steel pivot diameter 11 mm.
